7.5 Ton Crawler Excavator
TCE75
Features
Yanmar Powered Excavator with High Performance & Reach
The TCE75 combines a 44 kW Yanmar engine with a 0.28 m³ bucket and extended working reach, delivering strong digging force and high productivity. Its large working range supports efficient deep excavation and truck loading, making it suitable for demanding earthmoving and construction projects.
Large Flow Main Valve for 15% Higher Hydraulic Efficiency
Upgraded main valve with enlarged flow passages reduces pressure loss by up to 15%, improving hydraulic efficiency and delivering smoother, more responsive machine control.
Reinforced Boom Structure for Heavy Breaker Applications
The thickened boom design enhances structural rigidity and durability, making the machine more reliable when working with hydraulic breakers and high-impact tasks.
High-Low Travel Speed for Flexible Jobsite Movement
Dual-speed travel system improves mobility and climbing performance, allowing fast relocation and strong torque output on uneven terrain.
Hydraulic Breaker Line for Versatile Attachment Use
The TCE75 is equipped with a dedicated breaker pipeline, allowing quick connection to hydraulic breakers and other attachments. This expands machine versatility and improves efficiency in demolition, rock breaking, and heavy-duty construction tasks.
Hydraulic Oil Cooler for Stable High-Temperature Operation
The integrated oil radiator helps maintain optimal hydraulic oil temperature during continuous operation, preventing overheating, improving system stability, and extending hydraulic component service life in demanding working conditions.
Specifications
| Operating Weight | Kg | 7500 |
| Engine Model | Yammar 4TNV98 | |
| Rated Power | Kw | 44 |
| Bucket Capacity | m³ | 0.28 |
| Max Digging Force | Kn | 56 |
| Swing Speed | rpm | 0-11 |
| Traveling Speed | km/h | 2.8 |
| Gradeability | ° | 70(35°) |
| Operating Range | ||
| Max. Digging Radius | mm | 6182 |
| Max. Digging Depth | mm | 3898 |
| Max. Digging Height | mm | 7023 |
| Max. Dumping Height | mm | 5195 |
| Max. Dozer Cutting Distance | mm | 332 |
| Max. Dozer Lifting Distance | mm | 385 |
| Tail Swing Radius Distance | mm | 1730 |
| Overall Dimensions | ||
| Overall Length | mm | 6054 |
| Overall Width | mm | 2216 |
| Overall Height | mm | 2672 |
| Mini.Ground Clearance | mm | 375 |
| Track Width | mm | 450 |
| Undercarriage Width | mm | 2195 |
| Undercarriage Ground Clearance | mm | 375 |
