40 Ton Wheeled Excavator
TWE400
Features
Standard Rotary Orange Peel Grapple for Efficient Bulk Material Handling
The TWE400 comes standard with a rotary orange peel grapple designed for scrap steel, timber, and other bulk material handling applications. The rotating grapple improves material positioning flexibility, allowing operators to grab, rotate, and place materials more efficiently during continuous loading operations.
Hydraulic Elevating Cab for Better Visibility During High-Level Handling
The hydraulic elevating cab allows operators to raise the working position according to different loading conditions, providing a clearer view of trucks, material piles, and the grapple area. Improved visibility helps operators achieve more accurate grabbing and safer operation in large material yards.
Cummins Engine Platform with Global Service Support
Powered by a Cummins 6LTAA8.9 engine with 241kW output, the TWE400 provides reliable power for frequent grabbing, lifting, and loading cycles. The globally recognized Cummins platform offers strong brand confidence, convenient maintenance resources, and long-term operating support.
12.26m Working Range for Wider Operation Coverage
With a maximum grapple reach of 12,260mm, the TWE400 covers a larger working area while reducing frequent repositioning. The extended reach improves loading efficiency when handling materials in scrap yards, ports, recycling centers, and industrial storage areas.
Specifications
| Operating Weight | kg | 40000 |
| Engine Model | — | Cummins 6LTAA8.9 |
| Rated Power / Speed | kW / rpm | 241 / 2000 |
| Maximum Torque / Speed | N·m / rpm | 1400 / 1400 |
| Engine Displacement | L | 8.9 |
| Fuel Tank Capacity | L | 690 |
| Hydraulic Motor Displacement | ml/r | 180 |
| Working Pressure | MPa | 34 |
| Hydraulic Oil Tank Capacity | L | 450 |
| Swing Speed | rpm | 7 |
| Bucket Digging Force | kN | — |
| Arm Digging Force | kN | — |
| Minimum Turning Radius | mm | — |
| Travel Speed | km/h | 18 |
| Gradeability | % | 25 |
| Overall Length | mm | 10821 |
| Overall Width | mm | 3050 |
| Overall Height | mm | 3742 |
| Counterweight Ground Clearance | mm | 1505 |
| Minimum Ground Clearance | mm | 450 |
| Tail Swing Radius | mm | 3590 |
| Length to Center of Rollers | mm | 2985 |
| Tread Width | mm | 120-24 |
| Engine Hood Height | mm | 260 |
| Maximum Dozer Blade Digging Depth | mm | 125 |
| Grab Height (Hinge Point) | mm | 14000 |
| Maximum Grab Radius / Reach | mm | 12260 |
| Operator Sight Height | mm | 2875 (Low) / 5225 (High) |
| Movable Arm Length | mm | 7000 |
| Bucket Arm Length | mm | 5000 |
| Operation Room Size | mm | 1800 × 1000 × 1675 |
