Name: 36 Ton Crawler Excavator with Advanced Hydraulic System
Availability: InStock

Features
Specifications
Product Showcase
Gallery
FAQs
Related Products

Features

Industrial-Grade Hydraulic System for Precise Control and Efficiency

Equipped with a heavy-duty hydraulic circuit using proven industrial pump and valve components, the TCE360 provides reliable oil flow distribution and responsive control performance. The optimized hydraulic layout enhances cycle efficiency, improves digging precision, and ensures stable operation during continuous high-intensity working conditions.

High-Stability Undercarriage

Equipped with 600mm wide crawler tracks and a 9-roller undercarriage structure, the TCE360 delivers strong ground contact and improved machine balance. Combined with KYB travel motors, it ensures stable mobility and reliable traction on soft soil, rocky ground, and uneven construction sites.

Extended Working Range for Deep Excavation Performance

With a maximum digging depth of 7370mm and working height up to 10200mm, the TCE360 provides an extended operating envelope for trenching, loading, and foundation work. The optimized geometry improves cycle efficiency while reducing machine repositioning in large-scale job sites.

Compact Swing Design with Improved Jobsite Flexibility

Featuring a minimum swing radius of 4265mm, the TCE360 offers enhanced maneuverability in confined working environments. This allows efficient operation in urban construction sites, road projects, and narrow quarry spaces without sacrificing productivity.

Operator-Oriented Cabin with Structural Protection Design

The TCE360 is equipped with a reinforced protective cabin structure, air conditioning, and ergonomic hydraulic pilot controls, ensuring operator comfort and reduced fatigue. The high-visibility layout supports safer operation during long-hour excavation tasks.

Multi-Function Work Capability with Standard Hydraulic Piping

Factory-installed breaker piping and dual-speed travel function allow the TCE360 to support a wide range of attachments. This expands its use across demolition, rock breaking, and general earthmoving applications, improving overall equipment utilization.

Specifications

Operating Weight	Kg	36000
Engine Model		Cummins 6LTAA8
Rated Power	Kw/rpm	194/2200
Bucket Capacity	m³	1.6
Swing Speed	rpm	15.00
Traveling Speed	km/h	4.3/2.4
Gradeability	°	30°
Hydraulic System
Hydraulic system working pressure	Mpa	34
Hydraulic Pump		PNM
Hydraulic Valve		Nakagawa/Kawasaki
Swing Motor		Kawasaki + Nakagawa
Traveling Motor		Modern
Operating Range
Max. Digging Radius	mm	9850
Max. Digging Depth	mm	7370
Max. Digging Height	mm	10200
Max. Dumping Height	mm	7135
Min. Swing Radius	mm	4265
Overall Dimensions
Overall Length	mm	11184
Overall Width	mm	3190
Overall Height	mm	3180
Track Width	mm	2980
Track Height	mm	3655

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

Gallery

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
