Features

One Machine For Multiple Attachment Applications

The TCE30 supports digging, crushing, trench cleaning, drilling and dozing operations, allowing operators to switch between different attachments according to the task. Quick attachment changes help increase machine utilisation and make the 3-ton excavator more versatile across different jobs.

Upgraded Heavy-Duty Structure For Greater Stability

The TCE30 features newly upgraded structural components with thicker and heavier sections. This reinforced construction provides a more stable working platform and is designed to withstand the repeated loads encountered in demanding excavation operations.

Yanmar Power With EPA And Euro V Certification

The TCE30 comes standard with a Yanmar 388F three-cylinder diesel engine with both EPA and Euro V certification. It provides a reliable power solution while helping customers meet different emission requirements across international markets.

Load-Sensing Hydraulics For Coordinated Operation

The hydraulic system combines a Taifeng pump and valve with a piston pump and load-sensing valve. This configuration helps match hydraulic output to operating demands, supporting smooth and responsive movements during excavation and attachment work.

Open Cover Design Makes Maintenance More Accessible

The open cover design provides a spacious maintenance area, with key service points positioned within easy reach. This makes routine inspection and maintenance more convenient and can help reduce the time required for daily servicing.

High And Low Travel Speeds For Better Jobsite Mobility

High- and low-speed travel modes allow the TCE30 to adapt its travelling performance to different working conditions. The combination of dual-speed travel, full-hydraulic pilot control and side-swing capability gives operators greater control when moving and positioning the machine on site.

Specifications

Main Technical Specifications	Operating Weight	kg	3000
	Bucket Capacity	m³	0.075
	Travel Speed (Low / High)	km/h	2.6–4.5
	Gradeability	%	30
Working Range	Maximum Digging Height	mm	3980
	Maximum Dumping Height	mm	2660
	Maximum Digging Depth	mm	2500
	Maximum Digging Radius	mm	4230
	Side Swing Offset (Left / Right)	mm	345 / 510
Overall Dimensions	Overall Length	mm	3850
	Overall Width	mm	1500
	Overall Height	mm	2500
	Dozer Blade Width / Height	mm	1500 / 315
Engine	Engine Brand	—	YANMAR
	Engine Model	—	3TNV88F
	Maximum Power	kW	18.2
	Maximum Speed	rpm	2200
	Number of Cylinders	—	3
	Cooling Method	—	Water-Cooled
	Engine Oil Change Quantity	L	2.8–6.7
Capacities	Fuel Tank Capacity	L	20
Capacities	Hydraulic Oil Tank / System Volume	L	16 / 24.5

*NOTE: Specifications and configurations are subject to change due to continuous product upgrades and improvements without prior notice. All information is for reference only, and some features are optional. Please contact our international sales team for confirmation. Final specifications and configurations shall be subject to the official contract signed by both parties.

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

Gallery

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
