2.5m³ Concrete Mixer Truck
TCM25
Features
Hydraulic Torque Converter for Smooth Power Transfer
The 280 split hydraulic torque converter optimizes power transmission during starting, climbing, and low-speed heavy-load operation. It reduces drivetrain impact and provides smoother control when transporting concrete at full capacity.
Heavy-Load Travel Stability with Hydraulic Torque Converter
Equipped with a 10T hydraulic steering drive axle, TCM25 maintains stable steering response while carrying heavy concrete loads. The reinforced axle structure improves load support and allows smoother movement across uneven job sites where frequent direction changes are required.
Integrated Water & Maintenance System for Easier Jobsite Management
The digital water measurement system, hydraulic washing function, and waterproof wiring design simplify daily operation and maintenance. These features help operators complete concrete preparation, cleaning, and routine care more efficiently while reducing downtime caused by harsh working conditions.
Hydraulic Material Loading System for Easier Batch Preparation
The front-and-rear hydraulic controlled hopper simplifies loading operations and improves workflow efficiency, allowing operators to complete material handling tasks with less manual adjustment.
Operator Protection Package for Safer Daily Operation
TCM25 integrates a protective cab structure with reversing camera, climate control, emergency equipment, and safety accessories to improve operator awareness and working confidence in complex jobsite conditions.
Specifications
| Operating Weight | kg | 6600 |
| Engine | — | YUNNEI Engine, Four-Cylinder |
| Engine Power | kW | 76 |
| Transmission | — | TDER Torque Converter |
| Drive Axle | — | LIUFENG |
| Tire Size | — | 23.5-16 (Steel Wire Tyre) |
| Bucket Capacity | m³ | 0.35 |
| Mixing Capacity | m³ | 2.2–2.5 |
| Reduction Ratio | — | TDER Speed Reducer |
| Reducer | — | TDER |
| Travel Speed | km/h | High: 32.5; Low: 5.5 |
| Drive Type | — | 4×4 Four-Wheel Drive, Rear Steering |
| Water Tank Capacity | L | 370 |
| Fuel Tank Capacity | L | 180 |
