Features

Kubota Three-Cylinder Power For Reliable Daily Operation

The TCE18 is powered by a Japanese Kubota D722 three-cylinder diesel engine, delivering dependable power and proven reliability for daily excavation work. Its compact three-cylinder configuration is well suited to a 1.8-ton mini excavator while maintaining practical operating performance.

360° Slewing And 60° Side Swing For Confined Sites

The TCE18 can rotate through 360°, while the boom can swing 60° sideways to improve working flexibility around buildings, walls and other obstacles. This configuration allows the machine to reposition the digging area without constantly moving the entire machine.

Enlarged Cooling System For Longer Working Cycles

An enlarged radiator and fan help keep oil and coolant temperatures under control during demanding operations. The improved cooling capacity is especially valuable for high-load applications such as hydraulic breaker work, supporting longer operating periods and more consistent performance.

Centralized Maintenance Design Saves Service Time

Filters and electrical components are centrally arranged, while the oil drain outlet is routed outward for easier access. This practical maintenance layout simplifies routine inspection, servicing and oil changes, helping reduce unnecessary downtime.

Specifications

Main Technical Specifications	Operating Weight	kg	1800
	Bucket Capacity	m³	0.03
	Travel Speed	km/h	0–1.5
Working Range	Maximum Digging Radius	mm	3570
	Maximum Digging Depth	mm	2139
	Maximum Digging Height	mm	2716
	Maximum Dumping Height	mm	1920
	Maximum Deflection Angle	°	−59° to 59°
Hydraulic System	Main Pump Type / Model	—	Gear Pump / 310303
	Maximum Main Pump Flow Rate	L/min	25
	Multi-Way Valve	—	8-Spool Hydraulic Pilot-Controlled Valve
	Rated Set Pressure	MPa	18
	Maximum Set Pressure	MPa	20
	Travel Hydraulic Motor Model	—	BMV500
	Motor Displacement	—	500
	Swing Hydraulic Motor Model	—	2.5K
Engine	Engine Brand	—	Kubota
	Engine Model	—	D722 / D902 (Optional)
	Maximum Power	kW	10.4 / 11.8
	Maximum Speed	rpm	2500 / 2300
	Number of Cylinders	—	3
	Cooling Method	—	Water-Cooled
	Engine Oil Change Quantity	L	3.5
	Fuel Type	—	Diesel
	Fuel Grade	—	No. 0 / No. −10
	Theoretical Fuel Consumption	L/h	1.3–1.5
Transportation Dimensions	Transportation Length	mm	2565
	Transportation Width	mm	1100
	Transportation Height	mm	2425
	Counterweight Ground Clearance	mm	425
Attachment	Bucket Width	mm	400
Working Equipment	Boom Length	mm	1673
	Arm Length	mm	900
	Dozer Blade Width	mm	1100
Capacities	Fuel Tank Capacity	L	10
Capacities	Hydraulic Oil Tank Capacity	L	12
Undercarriage	Track Size	mm	200 × 72 × 43

*NOTE: Specifications and configurations are subject to change due to continuous product upgrades and improvements without prior notice. All information is for reference only, and some features are optional. Please contact our international sales team for confirmation. Final specifications and configurations shall be subject to the official contract signed by both parties.

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

Gallery

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
