Features

Cummins Engine with High Torque Reserve Power

Equipped with a Cummins QSF3.8 engine (93 kW), the TCE180 provides strong torque reserve and stable power output. Optional Kubota V3800 engine compliant with EPA and Euro 5 standards is available for different market requirements.

Kawasaki Positive Flow Hydraulic System for Higher Efficiency

The Kawasaki positive flow hydraulic system enables precise power matching, improving overall energy efficiency by 5%–8%, ensuring smoother operation and better fuel utilization under heavy-duty conditions.

Advanced Main Valve System with Intelligent Control Optimization

A high-quality branded main valve combined with an optimized control algorithm enhances hydraulic response accuracy, improving machine controllability and providing more intuitive operator interaction.

Reinforced Boom and Arm Structure for Extreme Durability

The stick lower section is reinforced with extended strengthening plates to resist impact from rocks, while the boom center and rear sections are structurally upgraded, significantly improving strength and service life.

Optimized Bucket for Smooth Digging Performance

The bucket is designed using advanced simulation optimization to improve digging trajectory efficiency. Wear-resistant materials reduce resistance and power loss, increasing bucket capacity to 0.8 m³ for higher productivity.

Specifications

Operating Weight	Kg	18000
Engine Model		Cummins QSF3.8
Rated Power	Kw	93KW/2200rpm
Bucket Capacity	m³	0.8
Max Digging Force	Kn	98
Swing Speed	rpm	0-12
Traveling Speed	km/h	2.8-4.2
Gradeability	°	30°
Operating Range
Max. Digging Radius	mm	8985
Max. Digging Depth	mm	5975
Max. Digging Height	mm	9430
Max. Dumping Height	mm	6960
Min. Swing Radius	mm	2725
Overall Dimensions
Overall Length	mm	8540
Overall Width	mm	2720
Overall Height	mm	2920
Axle Base	mm	3200
Wheel(track) Distance	mm	2120
Mini.Ground Clearance	mm	480
Track Width	mm	600
Undercarriage width	mm	2720

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

Gallery

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
