1.7 Ton Mini Excavator
TCE17A
Features
Real-Time Oil Temp System to Prevent Overheating Damage
The TCE17A is equipped with an integrated hydraulic oil temperature display, allowing operators to monitor system conditions in real time during operation. This helps prevent overheating under continuous working cycles, improving hydraulic stability and extending overall system lifespan in demanding excavation environments.
Low Ground Pressure Tracks for Soft & Sensitive Terrain
The reinforced 180mm track system provides excellent traction while reducing ground disturbance, making the machine suitable for operation in urban renovation zones, landscaping areas, agricultural land, and indoor demolition environments where surface protection is critical.
Compact Design for Tight Urban & Confined Job Sites
Designed for operation in narrow or congested areas, the TCE17A maintains strong digging capability while minimizing working footprint. Its compact structure enables efficient performance in city infrastructure projects, utility trenching, and small-scale construction where space is limited but productivity requirements remain high.
Hydraulic Attachment System for Multi-Tool Applications
With a standard auxiliary hydraulic circuit, the TCE17A supports attachments such as breakers, augers, and grapples. This transforms the machine into a multi-purpose compact work platform, reducing equipment dependency and increasing return on investment for contractors handling varied jobsite tasks.
Reinforced Structure for Heavy-Duty Daily Operation
Built with reinforced hydraulic cylinders and a durable undercarriage system, the TCE17A is engineered for repeated load cycles in small-to-medium construction environments. Standard features such as oil cooler and canopy protection further enhance operational reliability during long working hours.
Specifications
| Operating Weight | Kg | 1700 |
| Engine Model | LaidongLD385 | |
| Rated Power | Kw | 29Kw/39hp |
| Bucket Capacity | m³ | 0.04 |
| Bucket Width | mm | 400 |
| Max Digging Force | Kn | 14 |
| System Working Pressure | Mpa | 18 |
| Swing Speed | rpm | 12 |
| Traveling Speed | km/h | 2.8 |
| Gradeability | ° | 35 |
| Ground Pressure | Kpa | 25 |
| Operating Range | ||
| Max. Digging Distance | mm | 2500 |
| Max. Digging Depth | mm | 1900 |
| Max. Digging Height | mm | 2820 |
| Max. Dumping Height | mm | 2000 |
| Min. Turning Radius | mm | 1190 |
| Overall Dimensions | ||
| Overall Length | mm | 2250 |
| Overall Width | mm | 1100 |
| Overall Height | mm | 2200 |
| Min. Ground Clearance | mm | 380 |
| Track Ground Length | mm | 1370 |
| Track Width | mm | 180 |
