Name: 1.5 Ton Zero Tail Mini Excavator with Kubota Engine
Availability: InStock

Features
Specifications
Product Showcase
Gallery
FAQs
Related Products

Features

Zero Tail Compact Design for Safe Operation in Tight Spaces

TCE15 features a zero tail swing structure with a 1.5-ton compact body, allowing safe operation close to walls, buildings, and obstacles. It significantly reduces rear-end collision risk and improves efficiency in confined construction sites such as urban renovation and indoor demolition.

Kubota Engine with EPA & Euro 5 for Reliable Power

Powered by a Kubota 722 engine with EPA and Euro 5 certification, the TCE15 delivers reliable 10.2 kW output with strong fuel efficiency. This ensures consistent performance in different working environments while meeting modern emission requirements.

Reinforced Travel System with Higher Traction Performance

Equipped with a high-torque travel motor system, the TCE15 improves walking capability by 13%, delivering stronger climbing ability and smoother movement on uneven ground, soft soil, and construction sites.

Strengthened Boom System for Improved Lifting Capacity

Upgraded boom hydraulic cylinder with 15% increased diameter enhances lifting force and stability, allowing the machine to handle heavier loads more smoothly during digging and material handling tasks.

Specifications

Operating Weight	Kg	1500
Engine Model		Kubota D722
Rated Power	Kw	10.2KW/2500rpm
Bucket Capacity	m³	0.025
Bucket Width	mm	380
Max Digging Force	Kn	9
System Working Pressure	Mpa	20
Swing Speed	rpm	12-13
Traveling Speed	km/h	2.1~3.2
Gradeability	°	58
Ground Pressure	Kpa	23
Operating Range
Max. Digging Distance	mm	3529
Max. Digging Depth	mm	2017
Max. Digging Height	mm	2955
Max. Dumping Height	mm	2077
Min. Swing Radius	mm	1420
Overall Dimensions
Overall Length	mm	3329
Overall Width	mm	990
Overall Height	mm	2267
Min. Ground Clearance	mm	153
Track Ground Length	mm	1190
Track Width	mm	200

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

Gallery

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
