1.5 Ton Mini Excavator

TCE15A

  • Engine Power :

    19 kW

  • Operating Weight :

    1500 kg

  • Dig Depth :

    1800 mm

Best Mini Excavator
Best Mini Excavators
Best Mini Excavator For The Money

1.5 Ton Mini Excavator with Japanese Shimadzu Pump

Inquiry
Features
Compact Excavator with Shimadzu Gear Pump for Heavy Lifting



TCE15A features a 1.1-ton operating weight combined with a high-reliability Japanese Shimadzu PGP1010 gear pump, delivering stable hydraulic power for digging, trenching, and attachment use. Its compact dimensions allow precise work in confined areas while maintaining consistent performance under continuous load.

Heavy-Duty Dozer Blade with Optional 4-Way Angle Control for Precision Grading

The reinforced dozer blade provides efficient backfilling and ground leveling, improving productivity in site preparation and landscaping work. When upgraded to a 4-way adjustable blade, operators can control blade angles for more precise grading and material spreading, significantly enhancing versatility across uneven or confined working conditions.

Optional Enclosed Cab with Improved Visibility and Operator Comfort

The optional spacious cab is designed with a wide field of view and ergonomic control layout, helping operators maintain better situational awareness during operation. Its noise-reducing structure improves working comfort over long shifts, while the optimized seating position reduces fatigue, making it suitable for extended daily excavation tasks.

Optional Side Swing Boom for Flexible Trenching in Narrow Spaces

The optional side swing boom allows the TCE15A to shift the working arm left and right without repositioning the machine, significantly improving efficiency in confined job sites. This feature is especially useful for trenching along walls, fences, and obstacles, where frequent machine movement is limited. By reducing repositioning time, it enhances productivity while maintaining precise digging control in urban construction, landscaping, and utility maintenance work.

Standard Auxiliary Hydraulic Line for Breaker Attachment Ready Operation

TCE15A comes standard with a dedicated breaker hydraulic pipeline, allowing quick connection of hydraulic attachments such as breakers. This enables the machine to switch from digging to light demolition work without additional modifications, improving jobsite flexibility and reducing downtime in small construction and utility maintenance tasks.

Specifications
Operating Weight Kg 1500
Engine Model   LaidongLD380
Rated Power Kw 19kw/26hp
Bucket Capacity 0.03
Bucket Width mm 400
Max Digging Force Kn 12
System Working Pressure Mpa 18
Swing Speed rpm 12
Traveling Speed km/h 2.1
Gradeability ° 30
Ground Pressure Kpa 25
Operating Range
Max. Digging Distance mm 2500
Max. Digging Depth mm 1800
Max. Digging Height mm 2590
Max. Dumping Height mm 1850
Min. Turning Radius mm 1190
Overall Dimensions
Overall Length mm 2200
Overall Width mm 1100
Overall Height mm 2170
Min. Ground Clearance mm 380
Track Ground Length mm 1180
Track Width mm 180

Product Showcase

Best Mini Excavator

Why Choose TDER?



20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

Best Mini Excavators

Gallery
  • Images
FAQs



Are you a manufacturer or trading company?
TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.
What payment terms do you accept?
We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.
I am a first-time importer and don’t know the import process. What should I do?
We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.



What is the delivery time?
Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.
What about warranty?
Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.
Do you supply spare parts?
Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.
Do you have international certifications?
All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.
Can the machine be customized?
Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
