Features

Reinforced Working Equipment for Long-Term Durability

The TWE120 features a closed box-section welded boom and arm structure with reinforced main boom support, providing higher torsional resistance and structural strength. This design improves durability during repeated digging, loading and heavy-duty excavation operations.

Hydraulic Outriggers for Stable Excavation Performance

Equipped with hydraulic outriggers, the TWE120 provides a stable working platform during excavation. The reinforced support system helps reduce machine movement and improves safety when operating on uneven terrain or demanding job sites.

Ergonomic Cab Design with Enhanced Operator Visibility

The spacious cab features an ergonomic layout with optimized control positioning for easier operation. The low-profile upper structure improves side visibility, allowing operators to better monitor the working area and operate with greater confidence in busy construction environments.

Pilot Control System for Precise Multi-Function Operation

The pilot control system reduces operating effort while improving hydraulic control smoothness and precision. It allows operators to perform digging, rotation and attachment operations with better coordination and less fatigue during extended working hours.

Reliable Mobility with Durable Tires and Hydraulic Braking

Designed for frequent movement between job sites, the TWE120 adopts reinforced tires with high-performance rubber compounds for improved wear resistance and longer service life. The four-wheel hydraulic braking system provides reliable stopping performance with a simple structure for easier maintenance.

Efficient Power and Hydraulic System for Versatile Applications

Powered by a 74kW Yuchai YC4DK100 engine and equipped with Chuan Zhong hydraulic components, the TWE120 delivers stable power and hydraulic performance for excavation, loading and attachment operations. Standard configurations including breaker piping, hydraulic travel and air conditioning enhance machine versatility across municipal construction, road maintenance and general excavation applications.

Specifications

Operating Weight	kg	12000
Bucket Capacity	m³	0.4
Swing Speed	rpm	11
Gradeability	°	25
Maximum Bucket Digging Force	kN	75
Maximum Arm Digging Force	kN	52
Engine Model	—	YC4DK100
Engine Power / Speed	kW / rpm	74 / 2200
Tire Model	—	9.00-20
System Pressure	MPa	30
Maximum Digging Height	mm	8223
Maximum Dumping Height	mm	6300
Maximum Digging Depth	mm	4414
Maximum Vertical Digging Depth	mm	4032
Maximum Digging Radius	mm	7364
Minimum Swing Radius	mm	1989
Maximum Dozer Blade Lifting Distance	mm	430
Maximum Dozer Blade Cutting Depth	mm	60
Overall Dimensions (L × W × H)	mm	7284 × 2278 × 3011
Cabin Height	mm	3011
Wheelbase	mm	2500
Wheel Track	mm	1782
Minimum Ground Clearance	mm	335
Tail Swing Radius	mm	2159

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

Gallery

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
