10 Ton Wheeled Excavator
TWE100
Features
Yuchai Engine Power with Global Emission Options
Powered by the proven Yuchai 62.5kW diesel engine, TWE100 delivers reliable torque and fuel-efficient performance for continuous timber handling. An optional Euro V Yuchai engine is available to meet stricter emission requirements in international markets.
360° Rotating Grapple with Precision Pilot Control
The standard 360° hydraulic rotating grapple combined with pilot controls enables smooth, accurate log handling from every angle. Operators can load, stack, and position timber more efficiently while reducing manual repositioning and improving overall productivity.
Stable Hydraulic System for Continuous Heavy Lifting
The plunger pump and matched hydraulic system provide stable oil flow and consistent lifting performance during repetitive loading cycles. This improves operating efficiency while maintaining reliable hydraulic output under demanding forestry and timber yard conditions.
Reinforced Undercarriage for Rough Forestry Terrain
Equipped with a reinforced wheeled chassis, outriggers, and mechanical travel system, TWE100 maintains excellent machine stability during lifting while providing reliable mobility on logging roads, timber yards, and uneven ground.
Multi-Function Design for Higher Equipment Utilization
Standard breaker piping expands the machine beyond log handling, allowing quick adaptation to additional hydraulic attachments when required. Together with the enclosed cab, air conditioning, and cooling system, TWE100 provides year-round operating comfort and greater machine versatility.
Specifications
| Engine Model | — | Yuchai 4DK85 |
| Engine Type | — | Electronic Fuel Injection, Water-Cooled, Naturally Aspirated |
| Number of Cylinders | — | 4 |
| Engine Power | kW / rpm | 62.5 / 2200 |
| Swing Speed | rpm | 0–11 |
| Travel Speed | km/h | 0–28 (Max. 30) |
| Gradeability | ° | 20 |
| Overall Length | mm | 7070 |
| Overall Width | mm | 2205 |
| Overall Height | mm | 2850 |
| Ground Clearance | mm | 260 |
| Undercarriage Width | mm | 2250 |
| Dozer Blade Size | mm | 1880 × 350 |
| Fuel Tank Capacity | L | 120 |
| Hydraulic Oil Tank Capacity | L | 90 |
| Tire Size | — | 9.00-16 |
| Boom Length | mm | 4100 |
| Arm Length | mm | 2200 |
| Maximum Working Radius | mm | 7900 |
| Maximum Grapple Capacity | kg | 600 |
| Maximum Grapple Height | mm | 8200 |
| Maximum Dumping Height | mm | 5750 |
| Maximum Grapple Opening | mm | 1200 |
| Minimum Grapple Opening | mm | 150 |
| Tail Swing Radius | mm | 2000 |
