Features

Advanced Hydraulic Drive System for Smooth Operation

The TR08 is equipped with a full hydraulic travel system featuring a Sauer piston pump and Danfoss travel motors, delivering smooth power transmission and precise speed control. The hydraulic configuration improves operating stability and reduces mechanical effort during continuous compaction work.

Hydraulic Steering System for Precise Machine Control

Unlike conventional mechanical steering systems, the TR08 uses hydraulic steering with dedicated control operation, allowing direction changes with minimal physical effort. The all-wheel steering design improves maneuverability and positioning accuracy during pavement repair, road maintenance, and foundation preparation.

Simplified Vibration Control for Efficient Operation

The electromagnetic clutch vibration system enables quick vibration activation through simple control operation. Combined with the forced forward switch, the TR08 helps operators maintain efficient working cycles with fewer manual adjustments.

Japanese Components for Enhanced Durability

The TR08 uses Japanese NSK bearings and Mitsubishi V-belts to improve component durability and transmission reliability. These high-quality components help maintain stable performance during frequent compaction operations and reduce maintenance requirements over the machine’s service life.

Ergonomic Design for Better Visibility and Control

The TR08 features an ergonomic streamlined body design with an open operating view, allowing operators to monitor the working area more easily. The practical layout improves machine handling and helps operators perform compaction tasks with greater confidence.

Specifications

Weight	Net Weight	kg	720
	Operating Weight	kg	800
	Static Line Load	N/cm	61.5 / 65.5
Dimensions	Overall Width	mm	750
	Overall Length (Handle Folded)	mm	2500 / 1800
	Overall Height (Handle Upright)	mm	1140 / 1710
	Package Dimensions	mm	1320 × 700 × 1730
	Drum Width	mm	620
	Drum Diameter	mm	355
	Wheelbase	mm	650
Drive	Engine Brand	—	Changchai
	Engine Model	—	186
	Engine Type	—	Diesel Engine
	Number of Cylinders	—	1
	Output Power	kW	6
	Rated Speed	rpm	3600
	Electrical System Voltage	V	12
	Drive Mode	—	Full Hydraulic Drive
Travel Characteristics	Travel Speed	km/h	0-6
Travel Characteristics	Theoretical Gradeability	%	30
Brake	Working Brake	—	Variable Displacement Piston Pump
Steering	Steering Method	—	All-Wheel Steering
Vibration System	Vibrating Drums	—	Front + Rear
	Drive Form	—	Electromagnetic Clutch + Belt-Driven Vibration
	Vibration Frequency	Hz	65 / 60
	Vibration Amplitude	mm	0.5
	Exciting Force	kN	30
Sprinkler System	Sprinkler Type	—	Gravity Shower
Capacity	Hydraulic Oil Capacity	L	28
	Fuel Tank Capacity	L	5.5
	Water Tank Capacity	L	30

*NOTE: Specifications and configurations are subject to change due to continuous product upgrades and improvements without prior notice. All information is for reference only, and some features are optional. Please contact our international sales team for confirmation. Final specifications and configurations shall be subject to the official contract signed by both parties.

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
