Features

Ride-On Design for Improved Operator Productivity

The TR075 adopts a ride-on operating design, providing a more comfortable working position compared with traditional walk-behind rollers. The seating configuration reduces operator fatigue during extended compaction tasks, making it suitable for road maintenance, municipal construction, and surface preparation applications.

Smooth Variable Speed Control for Precise Operation

Equipped with a continuously variable speed system, the TR075 allows operators to adjust traveling speed smoothly according to different working conditions. The flexible speed control improves maneuverability during compaction near edges, curves, and changing surfaces.

Diesel Power for Economical and Reliable Operation

Powered by the Changchai diesel engine with electric start, the TR075 delivers reliable 8HP power output with convenient starting and economical fuel consumption. The proven diesel platform supports consistent operation in outdoor construction environments.

Simplified Controls for Easier Operation

The TR075 features one-button vibration activation through an electromagnetic clutch system, allowing operators to engage and disengage vibration quickly during compaction work. Combined with the continuously variable speed control, the simplified operation system helps improve working efficiency and reduce operator effort.

Rear Steering System for Flexible Maneuvering

The rear-wheel steering configuration provides responsive direction control and improved maneuverability in confined construction areas. Combined with the hydraulic front drum drive system, the TR075 offers smooth movement and precise positioning during compaction work.

Specifications

Travel	Travel Speed	km/h	0-6
	Gradeability	%	25
	Turning Radius	mm	1800
Compaction	Nominal Amplitude	mm	0.5
	Vibration Frequency	Hz	75
	Exciting Force	kN	25
Work	Drive System	—	Hydraulic Pump and Motor
	Vibration Type	—	One-Button Vibration - Electromagnetic Clutch, Front Drum Vibration
	Steering Type	—	Rear Wheel Steering
Engine	Engine Model	—	Changchai R180
	Engine Type	—	Water-Cooled Diesel Engine
	Rated Power	hp/rpm	8 / 2300
	Fuel Tank Capacity	L	5.5
	Optional Engines	—	Changfa 178 / Honda GX270 / Changchai R180 / Koop 178 / Briggs & Stratton (Other engines available upon request)
Dimensions	Drum Width	mm	700
	Drum Diameter	mm	530
	Overall Length	mm	1880
	Overall Width	mm	860
	Overall Height	mm	1250
Weight	Net Weight	kg	630
Weight	Operating Weight	kg	750
Packaging	Fumigation-Free Wooden Case Package	mm	1800 × 930 × 1300
Packaging	Steel Frame Stackable Package	mm	1850 × 900 × 2260

*NOTE: Specifications and configurations are subject to change due to continuous product upgrades and improvements without prior notice. All information is for reference only, and some features are optional. Please contact our international sales team for confirmation. Final specifications and configurations shall be subject to the official contract signed by both parties.

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
