730kg Skid Steer Loader
TDS45
Features
Multi-Engine Options for Regional Compliance & Job Flexibility
The TDS45 offers a standard 39kW Quanchai engine with optional Yanmar, Kubota, Kohler (EPA / Euro V), and Euro V Xinchai engines, allowing users to match power and emission requirements across different markets.
Tubeless Tire System for Stronger Site Adaptability
The 10-16.5 tubeless tires provide improved puncture resistance and better load stability compared to traditional pneumatic setups, reducing downtime caused by tire damage in construction and rough terrain conditions.
Integrated Safety Package for Clear Job Site Awareness
Standard features include LED lighting, warning light, reversing buzzer, and rearview camera, providing improved visibility and safer operation in busy job site environments.
Enhanced Cooling System for Continuous Working Stability
The large aluminum radiator improves heat dissipation efficiency, helping maintain stable engine performance during long working hours and high-load operation conditions.
Strong Lifting Capacity in Compact Size
With a rated load of 730kg and maximum load of 1460kg, the machine delivers reliable lifting capability for daily loading, stacking, and material transfer tasks, making it suitable for medium-duty job site operations.
Efficient Loading Height & Material Handling Capability
A 2266mm dumping height and 0.47m³ bucket capacity provide efficient material transfer into small trucks, containers, and site storage areas, reducing loading time per cycle.
Specifications
| Rated capacity | kg | 730 | |
| Rated flow | L/min | 80 | |
| High flow | L/min | --- | |
| Discharge height | mm | 2266 | |
| Discharge distance | mm | 662 | |
| Power type | Diesel | ||
| Control type | Manual control | ||
| Overall length with bucket | mm | 3348 | |
| Overall length without bucket | mm | 2522 | |
| Overall width with bucket | mm | 1800 | |
| Overall width without bucket | mm | 1730 | |
| Overall height | mm | 2070 | |
| Max. operating height | mm | 3850 | |
| Front turning radius | mm | 2027 | |
| Front turning radius without attachme | mm | 1380 | |
| Rear turning radius | mm | 1527 | |
| Wheel base | mm | 991 | |
| Tread | mm | 1465 | |
| Max. Speed | km/h | 12 | |
| Max. load | kg | 1460 | |
| Lifting type | Radius | ||
| Bucket capacity | M3 | 0.47 | |
| Total weight with bucket | kg | 2850 | |
| Tubeless tire | 10-16.5 | ||
| Engine model | Quanchai QC490GP | ||
| Power | kw | 39 | |
| Rotate speed at rated power | rpm | 2400 | |
| Displacement | L | 2.23 | |
