Name: 600kg Walk Behind Double Drum Roller with Japanese Engine
Availability: InStock

Features
Specifications
Product Showcase
FAQs
Related Products

Features

Wider Compaction Coverage Without Increasing Machine Size

The TR06-II features 700mm wide dual steel drums while maintaining a compact 600kg-class machine design. The wider drum configuration increases ground contact coverage during each pass, helping improve working efficiency in asphalt repair, pavement maintenance, and surface preparation applications without sacrificing maneuverability.

Gasoline Power for Convenient Operation and Easy Maintenance

Powered by the Honda GX390 gasoline engine, the TR06-II provides reliable 13HP performance with the advantages of gasoline operation, including convenient starting, simple maintenance, and strong adaptability for different jobsite environments. The proven engine platform makes the machine an efficient choice for contractors requiring flexible daily operation.

Designed for Smooth Control During Frequent Maneuvering

The hydraulic dual drum drive system provides stable forward and reverse movement, allowing operators to adjust machine position easily during repeated compaction tasks. The compact walk-behind design supports precise control around edges, corners, and small working areas.

Efficient Surface Finishing with Dual Drum Vibration

The automatic dual drum vibration system provides balanced compaction across both steel drums. The combination of wide drum coverage and consistent vibration performance makes the TR06-II suitable for projects requiring efficient surface finishing.

Specifications

Travel System	Travel Speed	km/h	0-6
	Gradeability	%	25
	Drive System	—	Hydraulic Pump and Motor
Engine	Engine Model	—	Honda GX390
	Engine Type	—	Gasoline Engine, Air-Cooled 4-Stroke
	Rated Power	hp/rpm	13 / 3600
	Fuel Tank Capacity	L	5.5
	Optional Engines	—	Changfa 180 / Honda GX390 / Changchai R180 / Briggs & Stratton (Other engines available upon request)
Compaction Performance	Nominal Amplitude	mm	0.5
	Vibration Frequency	Hz	75
	Exciting Force	kN	20 × 2
	Vibration Type	—	Automatic Vibration - Dual Drum Vibration
Capacity	Water Tank Capacity	L	20
	Water Tank Material	—	Steel Water Tank / Rotomolded Water Tank (Optional)
	Hydraulic Oil Tank Capacity	L	10
Working Specifications	Drum Width	mm	700
Working Specifications	Drum Diameter	mm	426
Dimensions	Overall Length (Handle Folded)	mm	2450
	Overall Width	mm	850
	Overall Height (Handle Raised)	mm	1520
Weight	Net Weight	kg	555
Weight	Operating Weight	kg	600
Packaging	Fumigation-Free Wooden Case Package	mm	1340 × 940 × 1340
Packaging	Steel Frame Stackable Package	mm	1340 × 900 × 2260

*NOTE: Specifications and configurations are subject to change due to continuous product upgrades and improvements without prior notice. All information is for reference only, and some features are optional. Please contact our international sales team for confirmation. Final specifications and configurations shall be subject to the official contract signed by both parties.

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
