600kg Walk Behind Road Roller
TR06-III
Features
Wide Drum Design for Stable Compaction Performance
The TR06-III features 700mm wide dual steel drums combined with a 600kg operating weight, providing a larger compaction contact area and stable ground pressure during operation. This configuration improves working efficiency for asphalt repair, road maintenance, and foundation preparation while maintaining the flexibility of a walk-behind roller.
Air-Cooled Diesel Power with Simple Maintenance
Powered by the Changchai air-cooled diesel engine, the TR06-III delivers reliable power performance with the advantages of a simple cooling structure and convenient maintenance. The diesel platform provides economical operation and strong adaptability for outdoor construction environments.
Advanced Coating Technology for Long-Term Protection
The machine adopts advanced painting technology to enhance surface protection against rust and corrosion. The durable coating improves resistance to outdoor exposure, helping maintain the equipment’s appearance and service life during long-term use.
Reliable Dual Drum Drive for Smooth Operation
The hydraulic pump and motor dual drum drive system provides stable travel performance, while the automatic dual drum vibration system delivers consistent compaction results. The practical mechanical structure helps ensure reliable operation with easy maintenance.
Specifications
| Travel | Speed | km/h | 0-6 |
| Climbing Ability | % | 25 | |
| Compaction | Nominal Amplitude | mm | 0.5 |
| Vibration Frequency | Hz | 70 | |
| Exciting Force | kN | 20 × 2 | |
| Water Tank Capacity | L | 25 | |
| Water Tank Material | — | Steel Water Tank / Rotomolded Water Tank (Optional) | |
| Hydraulic Oil Tank Capacity | L | 10 | |
| Work | Drive | — | Hydraulic Pump and Motor |
| Vibration | — | Centrifugal Clutch + Dual Drum Belt-Driven Vibration | |
| Engine | Engine Model | — | Changchai R180 (Water-Cooled) |
| Engine Type | — | Diesel Engine, Water-Cooled 4-Stroke | |
| Rated Power | hp/rpm | 8 / 2300 | |
| Fuel Tank Capacity | L | 3.5 | |
| Fuel Consumption Rate | g/kWh | 313 | |
| Dimensions | Drum Width | mm | 700 |
| Drum Diameter | mm | 426 | |
| Overall Length (Handle Folded) | mm | 2450 | |
| Overall Width | mm | 850 | |
| Overall Height (Handle Upright) | mm | 1520 | |
| Weight | Net Weight | kg | 570 |
| Operating Weight | kg | 600 |
*NOTE: Specifications and configurations are subject to change due to continuous product upgrades and improvements without prior notice. All information is for reference only, and some features are optional. Please contact our international sales team for confirmation. Final specifications and configurations shall be subject to the official contract signed by both parties.
