4.0 Ton Telescopic Loader
ZT940T
Features
Weichai Engine with Global Recognition and Lower Ownership Costs
Powered by a 129kW Weichai WP6G175E22 six-cylinder engine, the ZT940T benefits from Weichai’s strong reputation in the global industrial power market. The proven engine platform provides reliable quality, efficient fuel consumption, and convenient maintenance support through widely available service resources, helping customers reduce operating costs throughout the machine’s service life.
Meritor Axle for Superior Load Support and Durability
Equipped with a Meritor 30 axle, the ZT940T adopts a proven commercial-grade axle solution designed for demanding load-bearing applications. The reinforced axle structure provides excellent torque transfer capability, improved durability, and stable support when carrying heavy materials over long operating periods.
Pilot Hydraulic Control System for Accurate High-Position Handling
The hydraulic pilot single-handle control system, combined with boom damping and bucket angle control, allows operators to make smoother adjustments during lifting and unloading. These functions improve load positioning accuracy when working at extended boom heights.
Premium Cab Environment for Operator Endurance
The ZT940T features a luxury cab with an adjustable LCD display, aviation-style suspension seat, rear camera, LED lighting, heating system, and ergonomic controls. The optimized operator environment helps maintain productivity during long working shifts.
Specifications
| Rated load | kg | 4000 |
| Engnie | WEICHAI | |
| Rated Power | KW | 129 |
| Overall Length | mm | 7800 |
| Overall Width | mm | 2300 |
| Overall Height | mm | 3230 |
| Max. Discharge height | mm | 5400 |
| Min. Discharge height | mm | 4000 |
| Bucket Capacity | m³ | 2 |
| Bucket Type | Heavy-duty teeth | |
| Max. Load | 4000 including bucket or attachment | |
| Steering System | Articulated hydraulic steering | |
| Driving System | Four wheel drive | |
| Service Brake | Four Wheel Disk brake | |
| Parking Brake | Disc brake | |
| Tire Model | G2 pattern 20.5-25 Tyre G2 |
|
| Wheel base | mm | 2845 |
| Wheel Track | mm | 1825 |
| System pressure | Mpa | 19 |
| Weight | kg | 10000(with bucket) |
Product Showcase
Why Choose TDER?
20+ Years of Expertise
158 Countries Served
42,000㎡ of Advanced Production
Over $91M+ Annual Sales
