Name: 3.5 Ton Asphalt Road Roller with Poclain Motors
Availability: InStock

Features
Specifications
Product Showcase
FAQs
Related Products

Features

Full Hydraulic Drive for Precise Machine Control

The TRC203 features full hydraulic travel, all-wheel drive, hydraulic articulation, and front-wheel steering. Combined with continuously variable speed control, the system provides precise machine control and stable traction across different working conditions.

Poclain High-Torque Motors for Strong Traction

TFrench Poclain low-speed, high-torque hydraulic motors drive all four wheels, delivering strong traction at low travel speeds. This provides steady propulsion during repeated compaction passes and on demanding construction surfaces.

Dual-Drum Hydraulic Vibration for Consistent Compaction

TBoth steel drums use hydraulic vibration, allowing the front and rear drums to contribute to compaction. This dual-drum vibration system helps achieve more uniform compaction across roads, foundations, and backfilled areas.

Front and Rear Scrapers for Cleaner Drum Surfaces

Scrapers on both steel drums help remove soil, asphalt, and other material buildup during operation. Keeping the drum surfaces clean helps maintain consistent contact and compaction performance.

Intermittent Water Spraying for Asphalt Compaction

The TRC203 features front and rear water spraying systems with intermittent spray control. Water can be applied only when needed, helping keep the drums clean during asphalt compaction and reducing unnecessary water consumption. This makes the machine a practical asphalt road roller for municipal road maintenance and other paving applications.

Compact Design for Confined-Site Compaction

The compact double-drum design makes the TRC203 well suited to municipal roads, road maintenance, trench foundations, pipeline backfilling, construction sites, and sports grounds. Its small footprint allows effective compaction where larger rollers may have limited access.

Standard ROPS Canopy for Outdoor Operation

TThe standard rollover protective canopy provides added protection during outdoor construction work while maintaining an open operator area for practical visibility and access.

Specifications

Compaction	Operating Mass	kg	3500
	Static Linear Load (Front / Rear)	N/cm	136 / 136
	Vibration Amplitude	mm	0.5 / 0.5
	Exciting Force	kN	2 × 30
	Vibration Frequency	Hz	50
Travel	Travel Speed	km/h	0–12
	Gradeability	%	30
	Steering Angle	°	0
Dimensions	Overall Dimensions (L × W × H)	mm	2900 × 1400 × 2520
	Vibrating Drum Diameter	mm	700
	Vibrating Drum Width	mm	1250
	Rear Smooth Tire Quantity	pcs	—
	Rear Smooth Tire Specification	—	—
	Wheelbase	mm	2010
Engine	Diesel Engine Power	kW	26.5
Engine	Diesel Engine Model	—	ZN390B
Sprinkler System	Water Tank Capacity	L	200

*NOTE: Specifications and configurations are subject to change due to continuous product upgrades and improvements without prior notice. All information is for reference only, and some features are optional. Please contact our international sales team for confirmation. Final specifications and configurations shall be subject to the official contract signed by both parties.

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
