Name: 2.5 Ton Backhoe for Sale with Load Sensing Hydraulic System
Availability: InStock

Features
Specifications
Product Showcase
Gallery
FAQs
Related Products

Features

JCB-Type Loader Arm & Caterpillar-Style Excavator Arm Structure

ZT388-Ⅱ adopts a reinforced loader arm inspired by JCB design concepts and a Caterpillar-style excavator arm structure, improving overall digging strength, load stability, and structural durability under heavy-duty operation.

H-Type Hydraulic Side-Shift Outriggers with Free A-Type Option

The standard configuration features hydraulic side-shift H-type outriggers, allowing flexible positioning in confined job sites and improving overall working stability.

Users can also switch to A-type outriggers at no additional cost, enabling configuration flexibility based on different construction environments.

Advanced Hydraulic System with Load-Sensing Valve Technology

Equipped with a load-sensing valve system from Hydrotek, the hydraulic system automatically adjusts flow distribution according to working demand, improving energy efficiency and ensuring stable performance under variable load conditions.

4F/4R Mechanical Transmission for Durable Field Operation

The 4 forward and 4 reverse mechanical shift transmission provides simple structure, high reliability, and stable power delivery, making it suitable for harsh and continuous working conditions.

Selectable 2WD/4WD Axle System for Terrain Flexibility

Equipped with a Yunyu axle system featuring manual switching between 2WD and 4WD modes, the machine allows operators to adjust traction based on terrain conditions, improving fuel efficiency in light work and enhancing grip in heavy-duty or uneven job sites.

Safety Assistance System

The optional rear-view camera system improves visibility in blind spots during reversing and confined-space operations, helping operators better control machine positioning and reduce the risk of site collisions.

The boom safety guard provides additional structural protection for the lifting arm during heavy-duty excavation and loading, reducing the risk of accidental impact damage and improving overall working safety and equipment durability.

Specifications

Overall Dimensions	Dimensions (mm)	615023503763
	Wheel base (mm)	2200
	Track (mm)	1850/2000
	Minimum Ground Clearance (mm)	300
	Minimum Turning Radius (mm)	6580
Performance Parameters	System Pressure (Mpa)	28
	Total Weight (kg)	7400/8400
	Maximum Speed (Km/h)	38
	Maximum Climbing Ability (°)	35
Excavation Parameters	Maximum Telescopic Excavation Depth (mm)	4000/5200
	Excavation Unloading Height (mm)	4500/5300
	Maximum Excavation Radius (mm)	4800/6000
	Maximum Lifting Height (mm)	5200/5950
	Bucket Capacity (m³)	0.3
	Maximum Excavation Force (KN)	36
	Maximum Bucket Excavation Radius (mm)	840
	Excavator Rotation Angle (°)	190
Loading Parameters	Maximum Unloading Height (mm)	2700
	Maximum Unloading Distance (mm)	1062
	Bucket Capacity (m³)	1.2
	Lifting Force (KN)	72
Engine	Model	Yuchai
	Rated Power (KW)	75
	Rated Speed (r/min)	2600
	Cylinders-Bore (mm)	4-105
Transmission System	Gearbox	Mechanical Shift Transmission
	Number of Gears	4 Forward, 4 Reverse
	Liquid Torque Converter	Beilian ZL26
Axle	Brand	Yunyu
Tires		14-17.5/19.5L-24
	Driving Brake	Air Over Hydraulic Disc Brake
	Parking Brake	Air Brake
Oil Capacity	Fuel Tank (L)	100
Oil Capacity	Hydraulic Oil Tank (L)	100
Others	Drive Type	Four-wheel Drive
	Transmission Type	Liquid Transmission
	Control System	Electromagnetic Hydraulic Pilot Control

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

Gallery

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
