Name: 2 Ton Asphalt Roller with Rotomolded Water Tank
Availability: InStock

Features
Specifications
Product Showcase
FAQs
Related Products

Features

FHydraulic Vibration with Electronic Control for Consistent Results

Equipped with a front drum hydraulic vibration system and vibration solenoid valve control, the TR20 provides stable vibration output during compaction. The electronic delayed vibration start function helps reduce impact at the beginning of vibration operation, improving surface quality and operator control.

Large Rotomolded Water Tank for Reliable Asphalt Operation

The TR20 is equipped with a large-capacity rotomolded water tank that offers excellent corrosion resistance and long service life. Combined with an electric-controlled pressure spraying system, it provides more uniform water distribution and helps prevent asphalt material from sticking to the drum surface.

Service-Friendly Engine Access Design

The front engine hood can be opened at a wide angle, providing easier access to key components during inspection and maintenance. This practical design helps reduce service time and improve machine availability.

Specifications

Travel	Travel Speed	km/h	0-12
	Turning Radius	mm	2300
	Gradeability	%	30
Compaction	Static Line Load (Front / Rear)	N/cm	100 / 83
	Nominal Amplitude	mm	0.5
	Vibration Frequency	Hz	70
	Exciting Force	kN	30
Work	Drive Form	—	Hydraulic Dual-Wheel Drive
	Vibration Form	—	Hydraulic Vibration
	Steering Form	—	Hydraulic Steering
Sprinkler System	Sprinkler Type	—	Electrically Controlled Pressure Spraying
	Water Tank Type	—	Roto-Molded Water Tank
	Water Tank Capacity	L	108
Engine	Engine Model	—	Changchai ZN390 (China Stage II)
	Engine Type	—	Vertical 3-Cylinder, Water-Cooled Diesel Engine
	Output Power	HP / rpm	39 / 2600
	Fuel Tank Capacity	L	26
	Fuel Consumption Rate	g/kW·h	240
Dimensions	Front / Rear Drum Width	mm	1000
	Front / Rear Drum Diameter	mm	610
	Overall Length	mm	2350
	Overall Width	mm	1120
	Overall Height (Excluding ROPS)	mm	1600
	Overall Height (Including ROPS)	mm	2150
Brake	Parking Brake	—	Manual Brake
Capacity	Hydraulic Oil Tank Capacity	L	26
Weight	Net Weight	kg	1580
Weight	Operating Weight	kg	2000

*NOTE: Specifications and configurations are subject to change due to continuous product upgrades and improvements without prior notice. All information is for reference only, and some features are optional. Please contact our international sales team for confirmation. Final specifications and configurations shall be subject to the official contract signed by both parties.

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
