1.8 Ton Telescopic Loader
ZT918T
Features
Torque Converter Powertrain for Smooth Heavy-Load Operation
The ZT918T adopts a 265 integrated transmission with full hydraulic torque converter technology, delivering smooth torque output and stable power response during heavy loading operations. The hydraulic torque conversion system reduces mechanical impact during starting and reversing, improving driving comfort and extending drivetrain durability.
Mechanical Pilot Single-Joystick Control for Intuitive Operation
The ZT918T features a single joystick mechanical pilot-style control system, integrating multiple working functions into one easy-to-operate control interface. This layout simplifies boom and loading operations, allowing operators to work more efficiently with less complicated manipulation.
Four-Wheel Drive Platform with Herringbone Tires for Reliable Ground Adaptability
Equipped with four-wheel drive, wheel-side axles, and 23.5/70-16 herringbone tires, the ZT918T maintains stable grip and balanced handling when operating on farmland, construction areas, material yards, and uneven surfaces. The traction-focused tire design improves working confidence when carrying loads across challenging ground conditions.
High-Visibility Smart Cab for Safer and More Comfortable Operation
The ZT918T provides an upgraded operator environment with a large LCD dashboard, adjustable suspension seat, panoramic visibility, rear-view camera, LED lighting, heating system, and integrated cabin accessories. The improved visibility and ergonomic layout help operators maintain better awareness and comfort during extended working periods.
Integrated Hydraulic Working System for Faster Job Switching
The ZT918T is equipped with a four-section hydraulic valve and hydraulic quick-change system, allowing faster connection and control of different working equipment. This design improves preparation efficiency between different tasks and helps users adapt the machine to changing job requirements.
Specifications
| Rated load | kg | 1800 |
| Engnie | Yunnei YN27GB | |
| Rated Power | KW | 42 |
| Overall Length | mm | 5800 |
| Overall Width | mm | 1900 |
| Overall Height | mm | 2680 |
| Max. Discharge height | mm | 4500 |
| Min. Discharge height | mm | 3500 |
| Bucket Capacity | m³ | 0.75 |
| Bucket Type | Heavy-duty bolt on teeth | |
| Max. Load | 1800 including bucket or attachment | |
| Steering System | Articulated hydraulic steering | |
| Driving System | Four wheel drive | |
| Service Brake | Four wheel disc brake | |
| Parking Brake | Disc brake | |
| Tire Model | 23.5/70-16 | |
| Wheel base | mm | 2500 |
| Wheel Track | mm | 1500 |
| System pressure | Mpa | 16 |
| Weight | kg | 4500 |
