Features

Articulated Design for Flexible Maneuvering

Featuring an articulated connection structure, the TR12 improves steering flexibility and allows the machine to follow working paths more smoothly. The articulated design helps operators achieve accurate positioning during compaction, especially in curved sections and confined construction areas.

Hydraulic Dual Drive for Smooth Power Transmission

The TR12 adopts a hydraulic dual-drive system with Zhenjiang Dali travel motors and a variable piston pump, providing stable power delivery and smooth traveling performance. The hydraulic drive configuration reduces mechanical operation complexity and supports reliable movement across different jobsite conditions.

Stepless Speed Control for Better Working Adaptability

Equipped with a continuously variable speed system, the TR12 allows operators to adjust travel speed according to different compaction requirements. The flexible speed adjustment helps optimize working efficiency during asphalt paving, foundation preparation, and surface finishing operations.

Pressurized Water Spray System for Asphalt Applications

The TR12 features an electric-controlled pressure spraying system, ensuring consistent water distribution during asphalt compaction. The controlled spraying performance helps reduce material sticking to the drum surface and improves compaction quality.

Specifications

Travel	Travel Speed	km/h	0-8
	Turning Radius	mm	2000
	Gradeability	%	30
Compaction	Static Line Load (Front / Rear)	N/cm	77 / 56
	Nominal Amplitude	mm	0.5
	Vibration Frequency	Hz	75
	Exciting Force	kN	30
Work	Drive Form	—	Hydraulic Drive, Front & Rear Wheel Drive
	Vibration Form	—	One-Button Vibration with Electromagnetic Clutch
	Steering Form	—	Hydraulic Steering
Sprinkler System	Sprinkler Type	—	Electrically Controlled Pressure Spraying
	Water Tank Material	—	Roto-Molded Water Tank
	Water Tank Capacity	L	95
Capacity	Hydraulic Oil Tank Capacity	L	34
Capacity	Parking Brake	—	Manual Brake
Engine	Engine Model	—	Changfa 186
	Engine Type	—	Diesel, Air-Cooled 4-Stroke
	Output Power	hp / rpm	9 / 3600
	Fuel Tank Capacity	L	5.5
	Optional Engines	—	Changfa CF188 / Honda GX390 / Briggs & Stratton 25T2 / KIPOR 192
Dimensions	Front / Rear Drum Width	mm	700
	Front / Rear Drum Diameter	mm	530
	Overall Length	mm	2100
	Overall Width	mm	860
	Overall Height (Excluding Bumper)	mm	1470
	Fumigation-Free Wooden Case	mm	2200 × 950 × 1650
	Steel Frame Stacking Package	mm	2250 × 910 × 2560
Weight	Net Weight	kg	970
Weight	Operating Weight	kg	1200

*NOTE: Specifications and configurations are subject to change due to continuous product upgrades and improvements without prior notice. All information is for reference only, and some features are optional. Please contact our international sales team for confirmation. Final specifications and configurations shall be subject to the official contract signed by both parties.

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
