Name: 12 Ton Log Loader with Weichai Engine
Availability: InStock

Features
Specifications
Product Showcase
FAQs
Related Products

Features

Weichai Engine Power for Heavy Load Work

Powered by a 162kW Weichai WD10 engine platform, this log loader provides strong torque output for fast loading cycles and stable performance under heavy loads, ensuring efficient operation in continuous timber handling conditions.

Smooth Power Transfer with Heavy-Duty Transmission

The advanced gearbox system with countershaft transmission technology ensures efficient power transfer and strong overload adaptability, improving driving smoothness and maintaining stable performance during heavy material transport and lifting operations.

Enhanced Stability for Rough Terrain Operation

A heavy counterweight design combined with a long wheelbase and increased ground clearance enhances machine stability, allowing safe and reliable operation on uneven terrain, soft ground, and forestry working sites.

Reliable Brake System for Safe Load Control

A four-wheel dual-line caliper disc braking system with air-assisted storage ensures strong and responsive braking performance. Combined with optional rear-view camera and ROPS/FOPS cab structure, it significantly improves operator safety in high-risk working environments.

Durable Structure Built for Harsh Applications

Sealed articulation points and dust-proof structural protection improve durability in harsh working environments. The machine also supports customization for different lifting heights and working conditions, making it adaptable for various forestry and industrial loading tasks.

Specifications

Operating Weight	kg	20000
Rated Load	kg	12000
Engine Model	-	Weichai
Rated Power	kW	162
Rated Rotate Speed	r/min	2000
Max. Torque	N.m	≥920
Max. Dumping Height	mm	3600
Forward Gear I Speed	km/h	0-11.5
Forward Gear II Speed	km/h	0-38
Reverse Gear I Speed	km/h	0-16
Grade Ability	°	≥25
Overall Length	mm	8000
Overall Width	mm	2870
Overall Height	mm	3300
Turning Angle	°	35
Wheelbase	mm	3550
Wheel Tread	mm	2510
Cycling Time	s	14
Tire Model	-	23.5-25

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
