Features

100HP Platform for Heavy Implement Work

The TB1004 is the highest-power model in this group, combining 100HP output with a reinforced chassis designed to support heavier agricultural workloads. It is suited to intensive tillage, towing, transport, and operations involving larger mounted or hydraulic equipment.

Category II Hitch and Strong Lift for Larger Equipment

The Category II three-point hitch and strong-lift system provide the mounting and lifting capability required for heavier agricultural implements. This makes the TB1004 a suitable choice when equipment size and implement weight become important considerations in field operations.

Dual Hydraulic Circuits Expand Equipment Capability

With two hydraulic circuits and 2-in/2-out connections, the TB1004 can operate equipment requiring multiple hydraulic functions. This configuration gives the tractor greater flexibility for complex agricultural attachments rather than limiting it to basic mounted implements.

Specifications

Tractor Power	HP	100
Chassis Type	—	TB Chassis
Drive Type	—	4WD
Overall Length	mm	4050
Overall Width	mm	1830
Overall Height	mm	2660
Wheel Tread	mm	1300–1400
Wheelbase	mm	2110
Minimum Ground Clearance	mm	390
Minimum Service Weight	kg	3100
Engine Brand	—	Yangdong
Engine Origin	—	China
Emission Standard	—	Stage II
Engine Type	—	Inline, Direct Injection, Water-Cooled
Intake Method	—	Turbocharged
Engine Power	kW / rpm	66.15 / 2400
Fuel Type	—	Diesel
Fuel Tank Capacity	L	70
Suspension Type	—	3-Point Linkage, Category II
Hydraulic Output	Groups	2 Groups; 3 Groups Optional
Maximum Traction Force	kN	≥24.5
Maximum Lifting Capacity	kN	≥16
Rear PTO Speed	rpm	540 / 1000
PTO Spline	Spline	6
Steering System	—	Hydraulic Steering
Transmission	—	12F + 12R
Clutch Type	—	Dry-Type, Dual-Stage, Synchronized Shift
Brake Type	—	Oil-Immersed
Tire Size	—	Same as 80 HP
Forward Travel Speed	km/h	2.46–32.73
Reverse Travel Speed	km/h	2.15–28.69
Optional Equipment	—	ROPS, Canopy, Cabin with Air Conditioning, Air Compressor

Product Showcase

Why Choose TDER?

20+ Years of Expertise

158 Countries Served

42,000㎡ of Advanced Production

Over $91M+ Annual Sales

FAQs

Are you a manufacturer or trading company?

TDER is a China-based manufacturer with over 20 years of experience in machinery production and export. Our machines have been exported to 158 countries. We have our own factory covering 42,000 m², integrating R&D, manufacturing, and global sales.

What payment terms do you accept?

We support T/T, L/C, and O/A. Usually, a 30% deposit is required, and the remaining 70% balance should be paid before delivery.

I am a first-time importer and don’t know the import process. What should I do?

We provide full guidance for the import process, from documentation to customs clearance, to ensure a smooth transaction.

What is the delivery time?

Normally, it takes 15–30 days to ship after receiving your deposit. Standard products in stock can be shipped immediately, while customized products may require longer, depending on your order requirements.

What about warranty?

Generally, we offer a 12-month or 2,000 working hours warranty, whichever comes first. Some products may have longer or shorter warranty periods, so please confirm with our sales team before placing your order.

Do you supply spare parts?

Customers can purchase consumable parts together with the machine. For any future replacement, we provide genuine parts at cost price. Parts will be shipped via international express, usually arriving within 7–10 days.

Do you have international certifications?

All our products have CE certification and meet international standards. If you require additional certifications, please consult with our sales team for detailed information.

Can the machine be customized?

Yes, we support OEM/ODM customization including engine brand, color, attachments, and specifications etc.
